Specifications for the Tektelic KONA Micro Gateway
Table of Contents
- Dimensions
- Mechanical and Power Specifications
- LoRa Radio Specifications
- Network Interfaces
- Cellular Carrier Certifications
- Regulatory Compliance
- Manufacturer Documentation
Dimensions

Mechanical and Power Specifications
Mean Time Between Failure |
830,000 hours |
DC Power Consumption |
<7W |
Operating Temperature |
0°C to +40°C |
Operating Humidity |
5% to 95% non-condensing |
Battery Backup |
Up to 4 hours |
LoRa Radio Specifications
ISM Bands |
NA915, EU868, AS923, JP920, CH779 |
Transmission Power |
14dBm to 27dBm |
Receiver Sensitivity |
-139.5 dBm (SF12, 293 bits / sec) |
Receiver noise |
3.5 dB |
Receiver Linearity |
-10 dBm |
Network Interfaces
Ethernet Backhaul |
RJ-45 (10/100 BaseT) |
Cellular Backhaul |
3G/4G via internal antenna |
LoRa Antenna |
SMA-RC |
Cellular Carrier Certifications
- Verizon, AT&T, T-Mobile, Sprint, PTCRB
Regulatory Compliance
Safety |
IEC 60950-1 (CE) |
Environmental |
ETSI EN 300 019-2 |
Regulatory |
ETSI EN 55022 Class B ETSI EN 55024 ETSI EN 300 489-1/3 |
